| Part Number | G156XTN01.0 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AUO |
| Modell | G156XTN01.0 |
| diagonal Gréisst | 15.6 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1366(RGB)×768 [WXGA] 100PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 344.232(H)×193.536(V) mm |
| kontur dim. | 363.8(H)×215.9(V) ×9.6(D) mm |
| bezel Beräich | 350.4(H)×196.94(V) mm |
| Behandlung | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| luminance | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | 6 o'clock |
| Äntwert Zäit | 10 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/50/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 62% NTSC |
| Liichtquell | WLED , 50K hours , With LED Driver |
| Gewiicht | 860g (Typ.) |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
