| Part Number | G150XVN01.2 |
| Mark | AUO |
| Gréisst | 15.0 |
| Applikatioun | Industrial Medical I |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED |
| Interface | |
| Mark | AUO |
| diagonal Gréisst | 15.0 inch |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| aktiv Beräich | 304.128(H)×228.096(V) mm |
| bezel Beräich | 307.2(H)×231.1(V) mm |
| luminance | 400 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 262K/16.2M 72% NTSC |
| Gewiicht | TBD |
| Frame Taux | 60Hz |
| Modell | G150XVN01.2 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 326.5(H)×253.5(V) mm |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Äntwert Zäit | 20/15 (Typ.)(Tr/Td) |
| Betribssystemer Modus | MVA, Normally Black, Transmissive |
| Liichtquell | WLED , 50K hours , With LED Driver |
| entworf fir | Industrial Medical Imaging |
| Touch Panel | Without |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| G150XG02 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V1 | AUO | 15.0 | 1024×768 |
| G150XG03 V3 | AUO | 15.0 | 1024×768 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| G150XGE-L06 | Innolux | 15.0 | 1024×768 |
| G150XGE-L07 | Innolux | 15.0 | 1024×768 |
| G150XTN01.1 | AUO | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
