| Part Number | G150XTN03.8 |
| Mark | AUO |
| Gréisst | 15.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 262K/16.2M |
| Géigeliicht | WLED , 50K hours , With LED Driver |
| Interface | eDP |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 15.0 inch |
| Pixel Zuel | 1024(RGB)×768 (XGA) 85PPI |
| aktiv Beräich (mm) | 304.128 × 228.096 (H×V) |
| Bezel Beräich (mm) | 312.55 × 236.25 (H×V) |
| luminance | 400 cd/m² (Typ.) |
| Vue Wénkel | 80/80/70/80 (Typ.)(CR≥10) |
| gutt Vue op | - |
| Faarfdéift | 262K/16.2M 60% NTSC |
| mass | 720g (Max.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
| Modell Numm | G150XTN03.8 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| Behandlung | Antiglare, Hard coating (3H) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Äntwert | 5.7/3.2 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| G150XG02 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| G150XGE-L05 | Innolux | 15.0 | 1024×768 |
| G150XGE-L07 | Innolux | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
| G150XTT01.0 | AUO | 15.0 | 1024×768 |
