| Part Number | G150XAN01.0 |
| Mark | AUO |
| Gréisst | 15.0 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.2M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | G150XAN01.0 |
| Panel Gréisst | 15.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1024(RGB)×768, XGA, 85PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 304.128(W)×228.096(H) mm |
| bezel Ouverture | 309.9(W)×236.3(H) mm |
| Kontur Gréisst | 326.5(W)×253.5(H) ×9(D) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | AHVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| weisen Faarwen | 16.2M 60% NTSC |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 920g (Max.) |
| Applikatioun | Industrial |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
