| Part Number | G101STN01.F |
| Mark | AUO |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×600 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 10.1 inch |
| Pixel Zuel | 1024(RGB)×600 (WSVGA) 117PPI |
| aktiv Beräich (mm) | 222.72 × 125.28 (H×V) |
| luminance | - |
| Vue Wénkel | 70/70/60/60 (Typ.)(CR≥10) |
| gutt Vue op | - |
| Faarfdéift | 262K/16.7M |
| mass | - |
| Erfrëschungsrate | - |
| max. Bewäertungen | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| Modell Numm | G101STN01.F |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | - |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Äntwert | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| benotzt fir | Industrial |
| touchscreen | Without |
