| Part Number | EV190E0M-N50 |
| Mark | BOE |
| Gréisst | 19.0 |
| Applikatioun | Medical Imaging |
| Opléisung | 1280×1024 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | Grayscale |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | BOE |
| Panel Modell | EV190E0M-N50 |
| Panel Gréisst | 19.0" |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1280(LCR)×1024, SXGA, 86PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 374.784(W)×299.827(H) mm |
| bezel Ouverture | 378.8(W)×303(H) mm |
| Kontur Gréisst | 396(W)×324(H) ×10.4(D) mm |
| Uewerfläch | Antiglare (Haze 25%), Hard coating (3H) |
| Hellegkeet | 1300 cd/m² (Typ.) |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Display Modus | ADS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 14 (Typ.)(G to G) |
| weisen Faarwen | Grayscale |
| Lampe Typ | WLED , 50K hours , Without Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 1.69Kgs (Typ.) |
| Applikatioun | Medical Imaging |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Volt | 5.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
