| Part Number | EV156FHM-N10-5850 |
| Mark | BOE |
| Gréisst | 15.6 |
| Applikatioun | Industrial |
| Opléisung | 1920×1080 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | BOE |
| Modell | EV156FHM-N10-5850 |
| diagonal Gréisst | 15.6 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1080 [FHD] 141PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 344.16(H)×193.59(V) mm |
| kontur dim. | 363.8(H)×215.9(V) ×9.9(D) mm |
| bezel Beräich | 348.2(H)×197.6(V) mm |
| Behandlung | Antiglare |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 45% NTSC |
| Liichtquell | WLED [8S4P] , 50K hours , With LED Driver |
| Gewiicht | 850g (Max.) |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 70 °C ; Storage Temperature: -20 ~ 80 °C |
