| Part Number | EV121X0M-N10 |
| Mark | BOE |
| Gréisst | 12.1 |
| Applikatioun | Industrial |
| Opléisung | 1024×768 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1200:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | BOE |
| diagonal Gréisst | 12.1 inch |
| Pixel Format | 1024(RGB)×768 [XGA] 105PPI |
| aktiv Beräich | 245.76(H)×184.32(V) mm |
| bezel Beräich | 249(H)×187.5(V) mm |
| luminance | 500 cd/m² (Typ.) |
| Vue Richtung | Symmetry |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Gewiicht | 520g (Max.) |
| Frame Taux | 60Hz |
| Interface Typ | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | EV121X0M-N10 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Vertical Stripe |
| kontur dim. | 260.5(H)×204(V) ×9.2(D) mm |
| Behandlung | - |
| Kontrast Verhältnis | 1200:1 (Typ.) (TM) |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Liichtquell | WLED , 50K hours , With LED Driver |
| entworf fir | Industrial |
| Touch Panel | Without |
