| Part Number | EV101WUM-N20 |
| Mark | BOE |
| Gréisst | 10.1 |
| Applikatioun | Medical Imaging |
| Opléisung | 1920×1200 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | BOE |
| Modell | EV101WUM-N20 |
| diagonal Gréisst | 10.1 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 224PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 216.806(H)×135.504(V) mm |
| kontur dim. | 229.45(H)×149.22(V) mm |
| luminance | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 900:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | ADS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | WLED , W/O Driver |
| Gewiicht | - |
| entworf fir | Medical Imaging |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 45 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
