| Part Number | E295FCA62.A |
| Mark | EDO |
| Gréisst | 3.0 |
| Applikatioun | HMD VR AR |
| Opléisung | 1080×1200 |
| Zesummesetzung | AM-OLED, OLED |
| Hellegkeet | |
| CR | 10000:1 |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | MIPI |
| Mark | EDO |
| Modell | E295FCA62.A |
| diagonal Gréisst | 3.0 inch |
| Typ | AM-OLED, OLED |
| Pixel Format | 1080(RGB)×1200 446PPI |
| Configuratioun | Sub-Pixel Rendering |
| aktiv Beräich | 50.11(H)×55.68(V) mm |
| kontur dim. | 52.91(H)×62.58(V) ×0.75(D) mm |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 10000:1 (Min.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 2 (Typ.)(Tr+Tf) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥200) |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | 16.7M 109% NTSC |
| Liichtquell | self |
| Gewiicht | 4.80±0.40g |
| entworf fir | HMD VR AR |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| d-ic detail | COG Built-in RM67295 |
| Interface Typ | MIPI (4 data lanes) , 39 pins FPC |
| Stroumversuergung | 1.8/3.3/6.4/4.6/-2.5V (Typ.)(VDDI/VCI/VSP/ELVDD/ELVSS) |
| Ëmwelt | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -55 ~ 125 °C |
