| Part Number | CT024TN02 V.9 |
| Mark | Innolux |
| Gréisst | 2.4 |
| Applikatioun | Mobile Phone |
| Opléisung | 240×320 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 300:1 |
| Faarwen | 65K |
| Géigeliicht | WLED |
| Interface | |
| Mark | Innolux |
| Modell | CT024TN02 V.9 |
| diagonal Gréisst | 2.4 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 240(RGB)×320 [QVGA] 166PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 36.72(H)×48.96(V) mm |
| kontur dim. | - |
| luminance | - |
| Kontrast Verhältnis | 300:1 (Typ.) (TM) |
| Vue Richtung | 12 o'clock |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 45/45/50/20 (Typ.)(CR≥10) |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Ënnerstëtzung Faarf | 65K 60% NTSC |
| Liichtquell | WLED |
| Gewiicht | - |
| entworf fir | Mobile Phone |
| Frame Taux | - |
| Touch Panel | 4-wire Resistive Touch |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
