| Part Number | CLAA057VA01CW |
| Mark | CPT |
| Gréisst | 5.7 |
| Applikatioun | IA |
| Opléisung | 640×480 |
| Zesummesetzung | LCM |
| Hellegkeet | 220 |
| CR | 300:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | CPT |
| Panel Modell | CLAA057VA01CW |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 5.7 inch |
| Resolutioun | 640(RGB)×480 , VGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 116.16×87.12 mm |
| skizzéieren | 127×98.43×6.9 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 220 cd/m² (Typ.) |
| Kontrast Verhältnis | 300:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| Vue Wénkel | 70/70/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | TTL (1 ch, 6-bit), 40 pins |
| Input Volt | 3.3V (Typ.)(VCC) |
| Applikatioun | IA |
| CLAA050JA01CT | CPT | 5.0 | 480×272 |
| CLAA050LA0ACW | CPT | 5.0 | 800×480 |
| CLAA057VA01CW | CPT | 5.7 | 640×480 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| G057VTN01.1 | AUO | 5.7 | 640×480 |
| KG057QV1CA-G000 | Kyocera | 5.7 | 320×240 |
| LQ057AC111 | Other | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| DMF50773NF-SLY | Kyocera | 5.4 | 240×128 |
| G104VN01 V1 | AUO | 10.4 | 640×480 |
| LB064V02-A1 | LG Display | 6.4 | 640×480 |
| LMG5278XUFC-00T | KOE | 9.4 | 640×480 |
| LQ070Y1LG12 | SHARP | 7.0 | 800×480 |
| LQ9D168K | SHARP | 8.4 | 640×480 |
| LQ9D340 | SHARP | 8.4 | 640×480 |
| MD480L640PG4 | Panasonic | 10.4 | 640×480 |
| NL12876BC26-28 | NLT | 15.3 | 1280×768 |
| OEL9M0078-R-E | Other | 1.45 | 132×16 |
