| Part Number | C123VAN01.0 |
| Mark | AUO |
| Gréisst | 12.3 |
| Applikatioun | Automotive Display |
| Opléisung | 1440×540 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | |
| Faarwen | 16.7M |
| Géigeliicht | - |
| Interface | RSDS |
| Panel Mark | AUO |
| Panel Gréisst | 12.3" |
| Resolutioun | 1440(RGB)×540, 125PPI |
| Affichage Beräich | 291.6(W)×109.35(H) mm |
| Kontur Gréisst | 308.5(W)×129(H) mm |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M |
| Frequenz | 60Hz |
| Panel Gewiicht | 580±58g |
| Signal Interface | RSDS (1 Channel) FPC |
| Ëmwelt | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C |
| Panel Modell | C123VAN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 294.8(W)×112.35(H) mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Display Modus | AHVA, Normally Black, Transmissive |
| Äntwert Zäit | - |
| Lampe Typ | |
| Touchscreens | Without |
| Applikatioun | Automotive Display |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
