| Part Number | C084SAT01.1 |
| Mark | AUO |
| Gréisst | 8.4 |
| Applikatioun | Automotive Display |
| Opléisung | 800×600 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , No Driver |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Écran Gréisst | 8.4 inch |
| Pixel Zuel | 800×600(RGB) (SVGA) 118PPI |
| aktiv Beräich (mm) | 170.88 × 128.16 (H×V) |
| luminance | - |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M |
| mass | - |
| Erfrëschungsrate | 60Hz |
| max. Bewäertungen | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| Modell Numm | C084SAT01.1 |
| Écran Typ | LCM , a-Si TFT-LCD |
| Arrangement | RGB Horizontal Stripe |
| Kontur (mm) | - |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Äntwert | 15/20 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | AHVA, Normally Black, Transmissive |
| benotzt fir | Automotive Display |
| touchscreen | Without |
| AA084SB11 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| M084GNS1 R1 | IVO | 8.4 | 800×600 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| T-51639D084JU-FW-A-AB | Kyocera | 8.4 | 1024×768 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
