| Part Number | B156ZAN02.2 |
| Mark | AUO |
| Gréisst | 15.6 |
| Applikatioun | Laptop |
| Opléisung | 3840×2160 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | AUO |
| Modell | B156ZAN02.2 (AUO22EB) |
| diagonal Gréisst | 15.6 inch |
| Typ | LTPS TFT-LCD, LCM |
| Pixel Format | 3840(RGB)×2160 [UHD] 282PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 345.6(H)×194.4(V) mm |
| kontur dim. | 358.14(H)×224.4(V) ×3.2(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare |
| luminance | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | AHVA, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | WLED , 15K hours , With LED Driver |
| Form Stil | Slim (PCBA Flat, T≤3.2mm) |
| entworf fir | Laptop |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| B156HW01 V4 | AUO | 15.6 | 1920×1080 |
| CLAA156WA15A | CPT | 15.6 | 1366×768 |
| LP156WF1-TPB1 | LG Display | 15.6 | 1920×1080 |
| LP156WH2-TLQB | LG Display | 15.6 | 1366×768 |
| LTN156AT02-A11 | Samsung | 15.6 | 1366×768 |
| LTN156AT02-D02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-J08 | Samsung | 15.6 | 1366×768 |
| LTN156HT01-B01 | Samsung | 15.6 | 1920×1080 |
| N156B6-L06 | Innolux | 15.6 | 1366×768 |
| N156HGE-L11 | Innolux | 15.6 | 1920×1080 |
