| Part Number | B125HAN01.0 |
| Mark | AUO |
| Gréisst | 12.5 |
| Applikatioun | NBPC |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM |
| Hellegkeet | 400 |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | AUO |
| Panel Modell | B125HAN01.0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 12.5 inch |
| Resolutioun | 1920(RGB)×1080 , FHD |
| Display Modus | AHVA, Normally Black, Transmissive |
| aktiv Beräich | 276.48×155.52 mm |
| skizzéieren | 282.4×167.97×4.8 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) |
| weisen Faarwen | 262K (6-bit), CIE193150% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | WLEDEmbedded (LED Driver) |
| Signal Interface | eDP (2 Lanes), 30 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | NBPC |
| CLAA154WB04A | CPT | 15.4 | 1280×800 |
| HW14WX101 | BOE | 14.0 | 1366×768 |
| LP104V2-W | LG Display | 10.4 | 640×480 |
| LP133WF2-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP150E07-A3 | LG Display | 15.0 | 1400×1050 |
| LP156WH2-TLC2 | LG Display | 15.6 | 1366×768 |
| LTD121EXED | TOSHIBA | 12.1 | 1280×800 |
| N154I3-L03 | Innolux | 15.4 | 1280×800 |
| NV133FHM-N43 | BOE | 13.3 | 1920×1080 |
