| Part Number | B101XAN01.3 |
| Mark | AUO |
| Gréisst | 10.1 |
| Applikatioun | PAD |
| Opléisung | 1366×768 |
| Zesummesetzung | CELL |
| Hellegkeet | 0 |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Panel Mark | AUO |
| Panel Modell | B101XAN01.3 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Panel Gréisst | 10.1 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | AHVA, Normally Black, Transmissive |
| aktiv Beräich | 222.52×125.11 mm |
| skizzéieren | 230.62×135.81×0.805 mm |
| Uewerfläch | Hard coating, Antireflection |
| Glas Déift | 0.25+0.25 mm |
| Kontrast Verhältnis | 900:1 (Typ.) |
| weisen Faarwen | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Volt | 3.3V (Typ.) |
| Applikatioun | PAD |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| B101XAN02.0 | AUO | 10.1 | 1366×768 |
| B101XTN01.1 | AUO | 10.1 | 1366×768 |
| BT101IW04 V.0 | Innolux | 10.1 | 1024×600 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-B01 | HannStar | 10.1 | 1024×600 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| LTN101NT07-W01 | Samsung | 10.1 | 1024×600 |
| M101NWT4 R3 | IVO | 10.1 | 1024×600 |
| YXD101301000-60 | SEBO | 10.1 | 1024×600 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| BP080WX1-100 | BOE | 8.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LQ079L1SX02 | SHARP | 7.9 | 1536×2048 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
