| Part Number | AM480272H3TMQW-T00H |
| Mark | AMPIRE |
| Gréisst | 4.3 |
| Applikatioun | PND |
| Opléisung | 480×272 |
| Zesummesetzung | LCM |
| Hellegkeet | 250 |
| CR | 250:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | TTL |
| Panel Mark | AMPIRE |
| Panel Modell | AM480272H3TMQW-T00H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 4.3 inch |
| Resolutioun | 480(RGB)×272 , WQVGA |
| Display Modus | TN, Normally White, Transmissive |
| aktiv Beräich | 95.04×53.856 mm |
| skizzéieren | 105.5×67.2×5.26 mm |
| Uewerfläch | Antiglare, Hard coating (3H) |
| Hellegkeet | 250 cd/m² (Typ.) |
| Kontrast Verhältnis | 250:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit) |
| Äntwert Zäit | 40 (Typ.)(Tr+Td) |
| Vue Wénkel | 65/65/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 7S1PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 8-bit), 54 pins |
| Input Volt | 3.0V (Typ.) |
| Applikatioun | PND |
| 43WQW3T | SII | 4.3 | 480×272 |
| AA043MA01 | Mitsubishi | 4.3 | 800×480 |
| AM480272H3TMQW-T00H | AMPIRE | 4.3 | 480×272 |
| AM480272H3TMQW-TW2H | AMPIRE | 4.3 | 480×272 |
| AM480272H3TMQW-W2H | AMPIRE | 4.3 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T1DH04 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| DLC0500EZG-T-6 | Other | 5.0 | 800×480 |
| HSD043I9W1-B00 | HannStar | 4.3 | 480×272 |
| HST043BOH57-40AV0 | Other | 4.3 | 480×272 |
| LB035Q04-TD08 | LG Display | 3.5 | 320×240 |
| LMS430HF17-002 | Samsung | 4.3 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03A | SHARP | 4.3 | 480×272 |
| NL4827HC19-01B | NLT | 4.3 | 480×272 |
| PA040XS1 | E Ink | 4.0 | 320×234 |
