| Part Number | AM-19201200FTZQW-T05 |
| Mark | AMPIRE |
| Gréisst | 10.1 |
| Applikatioun | Industrial |
| Opléisung | 1920×1200 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | eDP |
| Panel Mark | AMPIRE |
| Panel Gréisst | 10.1" |
| Resolutioun | 1920(RGB)×1200, WUXGA, 224PPI |
| Affichage Beräich | 216.806(W)×135.504(H) mm |
| Kontur Gréisst | 227.72(W)×146.13(H) ×7.2(D) mm |
| Hellegkeet | 320 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 50% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | - |
| Signal Interface | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | AM-19201200FTZQW-T05 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | - |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | AHVA, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | WLED , 30K hours , With LED Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial |
