| Part Number | AM-19201200CTZQW-02 |
| Mark | AMPIRE |
| Gréisst | 10.1 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1920×1200 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | AMPIRE |
| Modell | AM-19201200CTZQW-02 |
| diagonal Gréisst | 10.1 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 225PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 216.576(H)×135.36(V) mm |
| kontur dim. | 244.8(H)×155.3(V) ×7.07(D) mm |
| luminance | 1000 cd/m² (Typ.) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | AHVA, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 49% NTSC |
| Liichtquell | WLED , 50K hours , With LED Driver |
| Gewiicht | - |
| entworf fir | Industrial Outdoor High Brightness |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (2 ch, 8-bit) , 45 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
