| Part Number | AM-1280800P4TZQW-T11H |
| Mark | AMPIRE |
| Gréisst | 7.0 |
| Applikatioun | Industrial |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S4P |
| Interface | |
| Panel Mark | AMPIRE |
| Panel Gréisst | 7.0" |
| Resolutioun | 1280(RGB)×800, WXGA, 217PPI |
| Affichage Beräich | 149.76(W)×93.6(H) mm |
| Kontur Gréisst | 162.3(W)×107.9(H) ×11.8(D) mm |
| Hellegkeet | 850 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 50% NTSC |
| Frequenz | 60Hz |
| Gewiicht | - |
| Panel Modell | AM-1280800P4TZQW-T11H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 152.76(W)×96.6(H) mm |
| Uewerfläch | - |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | SFT, Normally Black, Transmissive |
| Äntwert Zäit | 35 (Typ.)(Tr+Td) |
| Lampe Typ | 6S4P WLED , 50K hours , With LED Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial |
