| Part Number | AM-1280800N2TZQW-T28H |
| Mark | AMPIRE |
| Gréisst | 10.1 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1280×800 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | 16.7M |
| Géigeliicht | 7S6P |
| Interface | |
| Panel Mark | AMPIRE |
| Panel Gréisst | 10.1" |
| Resolutioun | 1280(RGB)×800, WXGA, 149PPI |
| Affichage Beräich | 216.96(W)×135.6(H) mm |
| Kontur Gréisst | 247(W)×166(H) ×8.95(D) mm |
| Hellegkeet | 850 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 45% NTSC |
| Frequenz | 60Hz |
| Gewiicht | 413g (Typ.) |
| Panel Modell | AM-1280800N2TZQW-T28H |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 220.76(W)×140.4(H) mm |
| Uewerfläch | - |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | IPS, Normally Black, Transmissive |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Lampe Typ | 7S6P WLED , 50K hours , Without Driver |
| Touchscreens | PCAP |
| Applikatioun | Industrial Outdoor High Brightness |
