| Part Number | AA106TA01DDE11 |
| Mark | Mitsubishi |
| Gréisst | 10.6 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 1280×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K/16.7M |
| Géigeliicht | WLED |
| Interface | |
| Mark | Mitsubishi |
| Modell | AA106TA01DDE11 |
| diagonal Gréisst | 10.6 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×768 [WXGA] 140PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 231.36(H)×138.816(V) mm |
| kontur dim. | 250(H)×175(V) ×15.5(D) mm |
| bezel Beräich | - |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 12/12 (Typ.)(Tr/Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | SWV, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 262K/16.7M 50% NTSC |
| Liichtquell | WLED , 100K hours , With LED Driver |
| Gewiicht | 670g (Typ.) |
| entworf fir | Industrial Outdoor High Brightness |
| Frame Taux | 60Hz |
| Touch Panel | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
