| Part Number | A050FTN01.0 |
| Mark | AUO |
| Gréisst | 5.0 |
| Applikatioun | Portable Navigation |
| Opléisung | 480×272 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6S2P WLED , 10K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | AUO |
| Modell Numm | A050FTN01.0 |
| Écran Gréisst | 5.0 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 480(RGB)×272 (WQVGA) 109PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 110.88 × 62.832 (H×V) |
| Kontur (mm) | 120.7 × 75.8 × 3.25 (H×V×D) |
| Bezel Beräich (mm) | 114.7 × 66.03 (H×V) |
| Behandlung | Antiglare, Hard coating (3H) |
| luminance | 500 cd/m² (Typ.) |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 70/70/40/60 (Typ.)(CR≥10) |
| Äntwert | 7/23 (Typ.)(Tr/Td) ms |
| gutt Vue op | - |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | 16.7M 50% NTSC |
| mass | 60.0g (Typ.) |
| benotzt fir | Portable Navigation MP3 PMP |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: 0 ~ 70 °C |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| G050VVN01.0 | AUO | 5.0 | 480×800 |
| HSD050I9W1-A00 | HannStar | 5.0 | 480×272 |
| LH500WF3-SH01 | LG Display | 5.0 | 1080×1920 |
| LM050QC1T01 | SHARP | 5.0 | 320×240 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| TM050QDH06 | Tianma | 5.0 | 640×480 |
