| Part Number | A050EAT01.0 |
| Mark | AUO |
| Gréisst | 5.0 |
| Applikatioun | Industrial |
| Opléisung | 1280×720 |
| Zesummesetzung | a-Si TFT-LCD, Assemb |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | AUO |
| Modell | A050EAT01.0 |
| diagonal Gréisst | 5.0 inch |
| Typ | a-Si TFT-LCD, Assembly |
| Pixel Format | 1280×720(RGB) [WXGA] 294PPI |
| Configuratioun | RGB Horizontal Stripe |
| aktiv Beräich | 110.4(H)×62.1(V) mm |
| kontur dim. | 136.38(H)×91.71(V) ×4.86(D) mm |
| luminance | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 20/15 (Typ.)(Tr/Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | - |
| Ënnerstëtzung Faarf | 16.7M 66% NTSC |
| Liichtquell | WLED [7S3P] , W/O Driver |
| Gewiicht | 63g (Typ.) |
| entworf fir | Industrial |
| Frame Taux | 60Hz |
| Touch Panel | PCAP |
| Interface Typ | MIPI (4 data lanes) , 42 pins Connector |
| Stroumversuergung | 1.8/3.3V (Typ.)(VDDI/VCI) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
