| Part Number | WG16080C1-YGH-VZ# |
| Mark | Winstar |
| Gréisst | 3.0 |
| Applikatioun | Industrial Instrumen |
| Opléisung | 160×80 |
| Zesummesetzung | STN-LCD , LCM |
| Hellegkeet | |
| CR | 3:1 |
| Faarwen | Monochrome |
| Géigeliicht | YG-LED |
| Interface | |
| Mark | Winstar |
| diagonal Gréisst | 3.0 inch |
| Pixel Format | 160×80 60PPI |
| aktiv Beräich | 67.17(H)×33.57(V) mm |
| bezel Beräich | 72.0(H)×40.0(V) mm |
| luminance | - |
| Vue Richtung | 6 o'clock |
| Vue Wénkel | 30/30/20/40 (Max.)(CR≥2) |
| Ënnerstëtzung Faarf | Monochrome |
| Gewiicht | - |
| Frame Taux | - |
| Modell | WG16080C1-YGH-VZ# |
| Typ | STN-LCD , LCM |
| Configuratioun | Rectangle |
| kontur dim. | 100(H)×54(V) ×14.6(D) mm |
| Behandlung | - |
| Kontrast Verhältnis | 3:1 (Typ.) (TM) |
| Äntwert Zäit | 200/250 (Typ.)(Tr/Td) |
| Betribssystemer Modus | STN, Blue/Grey (Positive), Transflective |
| Liichtquell | YG-LED , 100K hours , W/O Driver |
| entworf fir | Industrial Instruments & Meters |
| Touch Panel | Without |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| AL2004A | Other | 3.0 | 20×4 |
| C-51505NFJ-SLW-APN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LG-AKN | Kyocera | 3.0 | 20×2 |
| C-51505NFQJ-LW-ALN | Kyocera | 3.0 | 20×2 |
| DMC-20261NY-LY-CCE-CMN | Kyocera | 3.0 | 20×2 |
| DMC-20261NYJ-LY-CKE-CNN | Kyocera | 3.0 | 20×2 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| TM030ZDHG01 | Tianma | 3.0 | 320×320 |
