| Part Number | WG12232D-YYH-V |
| Mark | Winstar |
| Gréisst | 1.9 |
| Applikatioun | Industrial Instrumen |
| Opléisung | 122×32 |
| Zesummesetzung | LCM , STN-LCD |
| Hellegkeet | |
| CR | 3:1 |
| Faarwen | Monochrome |
| Géigeliicht | YG-LED , 100K hours , With LED Driver |
| Interface | 8-bit |
| Fabrikant beschwéiert | Winstar |
| Écran Gréisst | 1.9 inch |
| Pixel Zuel | 122×32 67PPI |
| aktiv Beräich (mm) | 45.72 × 11.97 (H×V) |
| Bezel Beräich (mm) | 52.0 × 15 (H×V) |
| luminance | - |
| Vue Wénkel | 30/30/20/40 (Typ.)(CR≥2) |
| gutt Vue op | 6 o'clock |
| Faarfdéift | Monochrome |
| mass | - |
| Erfrëschungsrate | - |
| Signal Typ | 8-bit 6800 parallel , 18 pins Pad |
| Spannungsversuergung | 5.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Modell Numm | WG12232D-YYH-V |
| Écran Typ | LCM , STN-LCD |
| Arrangement | Rectangle |
| Kontur (mm) | 59 × 29.3 × 5.5 (H×V×D) |
| Behandlung | - |
| Kontrast Verhältnis | 3 : 1 (Typ.) (TM) |
| Äntwert | 100/100 (Typ.)(Tr/Td) ms |
| Aarbecht Modus | STN, Yellow/Green (Positive), Transflective |
| benotzt fir | Industrial Instruments & Meters |
| touchscreen | Without |
| SG12832A | Other | 1.9 | 128×32 |
