| Part Number | WG12232A-YYH-N#A |
| Mark | Winstar |
| Gréisst | 2.2 |
| Applikatioun | Industrial Instrumen |
| Opléisung | 122×32 |
| Zesummesetzung | LCM, STN-LCD |
| Hellegkeet | |
| CR | 3:1 |
| Faarwen | Monochrome |
| Géigeliicht | YG-LED , 50K hours , No Driver |
| Interface | |
| Fabrikant beschwéiert | Winstar |
| Modell Numm | WG12232A-YYH-N#A |
| Écran Gréisst | 2.2 inch |
| Écran Typ | LCM, STN-LCD |
| Pixel Zuel | 122×32 57PPI |
| Arrangement | Rectangle |
| aktiv Beräich (mm) | 53.64 × 15.64 (H×V) |
| Kontur (mm) | 84 × 44 × 13.7 (H×V×D) |
| Bezel Beräich (mm) | 60.0 × 18.0 (H×V) |
| Behandlung | - |
| luminance | - |
| Kontrast Verhältnis | 3 : 1 (Typ.) (TM) |
| Vue Wénkel | 30/30/20/40 (Max.)(CR≥2) |
| Äntwert | 200/200 (Typ.)(Tr/Td) ms |
| gutt Vue op | 6 o'clock |
| Aarbecht Modus | STN, Yellow/Green (Positive), Transflective |
| Faarfdéift | Monochrome |
| mass | - |
| benotzt fir | Industrial Instruments & Meters |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
