| Part Number | WF57STIACDNT0 |
| Mark | Winstar |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | Grayscale |
| Géigeliicht | WLED , No Driver |
| Interface | 8/16-bit |
| Fabrikant beschwéiert | Winstar |
| Modell Numm | WF57STIACDNT0 |
| Écran Gréisst | 5.7 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 320×240 (QVGA) 70PPI |
| Arrangement | Rectangle |
| aktiv Beräich (mm) | 115.2 × 86.4 (H×V) |
| Kontur (mm) | 160 × 109 × 9 (H×V×D) |
| Bezel Beräich (mm) | 118.2 × 87.4 (H×V) |
| Behandlung | Antiglare |
| luminance | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 800 : 1 (Typ.) (TM) |
| Vue Wénkel | - |
| Äntwert | - |
| gutt Vue op | 12 o'clock |
| Aarbecht Modus | TN, Normally White, Transmissive |
| Faarfdéift | Grayscale |
| mass | - |
| benotzt fir | Industrial |
| Erfrëschungsrate | - |
| touchscreen | 4-wire Resistive Touch |
| Signal Typ | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , FPC 22 pins |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AA057VF12 | Mitsubishi | 5.7 | 640×480 |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| C555001 | SII | 5.7 | 320×240 |
| CLAA057VC01CT | CPT | 5.7 | 640×480 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| NL6448BC18-01F | NLT | 5.7 | 640×480 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
