| Part Number | WF57STIACDNN0 |
| Mark | Winstar |
| Gréisst | 5.7 |
| Applikatioun | Industrial |
| Opléisung | 320×240 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 800:1 |
| Faarwen | Grayscale |
| Géigeliicht | WLED |
| Interface | 8/16-bit |
| Panel Mark | Winstar |
| Panel Gréisst | 5.7" |
| Resolutioun | 320×240, QVGA, 70PPI |
| Affichage Beräich | 115.2(W)×86.4(H) mm |
| Kontur Gréisst | 160(W)×109(H) ×7.5(D) mm |
| Hellegkeet | 1000 cd/m² (Typ.) |
| Vue Wénkel | - |
| beschte Vue op | 12 o'clock |
| weisen Faarwen | Grayscale |
| Frequenz | - |
| Panel Gewiicht | - |
| Signal Interface | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Modell | WF57STIACDNN0 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | Rectangle |
| bezel Ouverture | 122.0(W)×92.0(H) mm |
| Uewerfläch | Glare (Haze 0%) |
| Kontrast Verhältnis | 800:1 (Typ.) (TM) |
| Display Modus | TN, Normally White, Transmissive |
| Äntwert Zäit | - |
| Lampe Typ | WLED , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
