| Part Number | WF39BTLASDNN0 |
| Mark | Winstar |
| Gréisst | 3.9 |
| Applikatioun | Industrial Stretched |
| Opléisung | 480×128 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | Winstar |
| diagonal Gréisst | 3.9 inch (1/2 cut of 4.3") |
| Pixel Format | 480×128(RGB) 128PPI |
| aktiv Beräich | 95.04(H)×25.34(V) mm |
| bezel Beräich | 97.04(H)×27.34(V) mm |
| luminance | 500 cd/m² (Typ.) |
| Vue Richtung | 6 o'clock |
| Vue Wénkel | - |
| Ënnerstëtzung Faarf | 16.7M |
| Gewiicht | - |
| Frame Taux | - |
| Interface Typ | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Modell | WF39BTLASDNN0 |
| Typ | a-Si TFT-LCD , LCM |
| Configuratioun | RGB Horizontal Stripe |
| kontur dim. | 105.5(H)×37(V) ×3.25(D) mm |
| Behandlung | Antiglare |
| Kontrast Verhältnis | 500:1 (Typ.) (TM) |
| Äntwert Zäit | - |
| Betribssystemer Modus | TN, Normally White, Transmissive |
| Liichtquell | WLED , W/O Driver |
| entworf fir | Industrial Stretched Bar LCD |
| Touch Panel | Without |
