| Part Number | WB014ZNM-N00 |
| Mark | BOE |
| Gréisst | 1.39 |
| Applikatioun | Wearable Round Displ |
| Opléisung | 454×454 |
| Zesummesetzung | AM-OLED , OLED |
| Hellegkeet | |
| CR | 20000:1 |
| Faarwen | 16.7M |
| Géigeliicht | self |
| Interface | MIPI |
| Panel Mark | BOE |
| Panel Gréisst | 1.39" |
| Resolutioun | 454(RGB)×454, 325PPI |
| Affichage Beräich | 35.412(W)×35.412(H) mm |
| Kontur Gréisst | 38.212(W)×39.372(H) mm |
| Hellegkeet | 350 cd/m² (Typ.) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 16.7M 103% NTSC |
| Frequenz | 60Hz |
| Chauffeur ic | COG Built-in RM67162FI |
| Panel Gewiicht | 2.64g |
| Signal Interface | MIPI (1 data lane) , 20 pins Connector |
| Input Volt | 1.8/3.0/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) |
| Ëmwelt | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
| Panel Modell | WB014ZNM-N00 |
| Panel Typ | AM-OLED , OLED |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | With Polarizer |
| Kontrast Verhältnis | 20000:1 (Typ.) (TM) |
| Display Modus | - |
| Äntwert Zäit | 3 (Max.)(Tr+Td) |
| Lampe Typ | self |
| Touchscreens | Without |
| Applikatioun | Wearable Round Display |
