| Part Number | VVX31P153H00 |
| Mark | Panasonic |
| Gréisst | 31.0 |
| Applikatioun | Desktop Monitor Indu |
| Opléisung | 4096×2160 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | Panasonic |
| Panel Gréisst | 31.0" |
| Resolutioun | 4096(RGB)×2160, 149PPI |
| Affichage Beräich | 697.958(W)×368.064(H) mm |
| Kontur Gréisst | 725.9(W)×401.6(H) ×29.7(D) mm |
| Hellegkeet | 350 cd/m² (Typ.) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 1.07B |
| Frequenz | 60Hz |
| Panel Gewiicht | 4.20Kgs (Typ.) |
| Signal Interface | LVDS (8 ch, 10-bit) , 184 pins Connector |
| Input Volt | 12V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 40 °C ; Storage Temp.: -20 ~ 50 °C |
| Panel Modell | VVX31P153H00 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 702(W)×372.1(H) mm |
| Uewerfläch | Antiglare |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Display Modus | IPS Pro, Normally Black, Transmissive |
| Äntwert Zäit | 11/9 (Typ.)(Tr/Td) |
| Lampe Typ | WLED , 30K hours , With LED Driver |
| Touchscreens | Without |
| Applikatioun | Desktop Monitor Industrial Medical Imaging |
