| Part Number | VLT550-SBL-FHD-226.8 |
| Mark | Vitrolight |
| Gréisst | 48.5 |
| Applikatioun | Digital Signage Stre |
| Opléisung | 1920×360 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | Vitrolight |
| Modell | VLT550-SBL-FHD-226.8 |
| diagonal Gréisst | 48.5 inch (1/3 cut of 55") |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×360 40PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 1209.6(H)×226.8(V) mm |
| kontur dim. | 1238.5(H)×259.3(V) ×26.5(D) mm |
| bezel Beräich | 1215.5(H)×233.3(V) mm |
| Behandlung | - |
| luminance | 600 cd/m² (Typ.) |
| Kontrast Verhältnis | 5000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 6 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥20) |
| Betribssystemer Modus | SVA, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 1.07B 72% NTSC |
| Liichtquell | WLED , W/O Driver |
| Gewiicht | - |
| entworf fir | Digital Signage Stretched Bar LCD |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (2 ch, 10-bit) Connector |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C - |
