| Part Number | VLT320-SBL-FHD-257 |
| Mark | Vitrolight |
| Gréisst | 29.3 |
| Applikatioun | Digital Signage Stre |
| Opléisung | 1920×708 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | Vitrolight |
| Panel Modell | VLT320-SBL-FHD-257 |
| Panel Gréisst | 29.3" (2/3 cut of 32") |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1920(RGB)×708, 69PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 698.4(W)×257.4(H) mm |
| bezel Ouverture | 704.1(W)×259.04(H) mm |
| Kontur Gréisst | 728.27(W)×289.04(H) ×26.5(D) mm |
| Uewerfläch | - |
| Hellegkeet | 700 cd/m² (Typ.) |
| Kontrast Verhältnis | 5000:1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥20) |
| Display Modus | SVA, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 8 (Typ.)(G to G) |
| weisen Faarwen | 16.7M 72% NTSC |
| Lampe Typ | WLED |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | - |
| Applikatioun | Digital Signage Stretched Bar LCD |
| Signal Interface | LVDS (2 ch, 8-bit) Connector |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; - |
