| Part Number | VLT170-SBL-SXGA-135 |
| Mark | Vitrolight |
| Gréisst | 14.3 |
| Applikatioun | Stretched Bar LCD Di |
| Opléisung | 1280×512 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | Vitrolight |
| Panel Modell | VLT170-SBL-SXGA-135 |
| Panel Gréisst | 14.3" (1/2 cut of 17.0") |
| Panel Typ | a-Si TFT-LCD, LCM |
| Resolutioun | 1280(RGB)×512, 96PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 337.92(W)×135(H) mm |
| bezel Ouverture | 341.92(W)×140.85(H) mm |
| Kontur Gréisst | 358.5(W)×162(H) ×10.3(D) mm |
| Uewerfläch | - |
| Hellegkeet | 400 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/80/80 (Typ.)(CR≥10) |
| Display Modus | TN, Normally White, Transmissive |
| beschte Vue op | - |
| Äntwert Zäit | 3.8 (Typ.)(G to G) |
| weisen Faarwen | 16.7M 72% NTSC |
| Lampe Typ | WLED |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | - |
| Applikatioun | Stretched Bar LCD Digital Signage |
| Signal Interface | LVDS (2 ch, 8-bit) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; - |
