| Part Number | V750DJ1-Q02 |
| Mark | Innolux |
| Gréisst | 75 |
| Applikatioun | TV Sets |
| Opléisung | 3840×2160 |
| Zesummesetzung | a-Si TFT-LCD , CELL |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 1.07B |
| Géigeliicht | No |
| Interface | V-by-One |
| Panel Mark | Innolux |
| Panel Gréisst | 75" |
| Resolutioun | 3840(RGB)×2160, UHD, 59PPI |
| Affichage Beräich | 1650.24(W)×928.26(H) mm |
| Kontur Gréisst | 1662.24(W)×941.96(H) ×1.32(D) mm |
| Hellegkeet | 0 cd/m² |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| Glas Déift | 0.50+0.50 mm |
| weisen Faarwen | 1.07B 72% NTSC |
| Frequenz | 60Hz |
| Chauffeur ic | COF Built-in 24 source + 16 gate chips |
| Panel Gewiicht | 4.66±0.23Kgs |
| Signal Interface | V-by-One 8 lane , 51 pins Connector |
| Input Volt | 12.0V (Typ.) |
| Ëmwelt | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Modell | V750DJ1-Q02 |
| Panel Typ | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | - |
| Uewerfläch | Antiglare (Haze 1%), Hard coating (3H) |
| Kontrast Verhältnis | 5000:1 (Typ.) (TM) |
| Display Modus | Super MVA, Normally Black, Transmissive |
| Äntwert Zäit | 9.5 (Typ.)(G to G) |
| transmissivitéit | 5.0% (Typ.)(with Polarizer) |
| Lampe Typ | No B/L |
| Touchscreens | Without |
| Applikatioun | TV Sets |
