V500HJ1-PE8 Rev.C3

V500HJ1-PE8 Rev.C3
V500HJ1-PE8 Rev.C3
V500HJ1-PE8 Rev.C3 thumb V500HJ1-PE8 Rev.C3 thumb
Mark
Chimei Innolux
Gréisst
50
Applikatioun
Transparent Display
Opléisung
1920×1080
Zesummesetzung
a-Si TFT-LCD , CELL
Hellegkeet
CR
5000:1
Faarwen
16.7M
Backlight
No
Interface
LVDS
In Stock
6614
Spezifikatioune

Part Number V500HJ1-PE8 Rev.C3
MarkChimei Innolux
Gréisst50
ApplikatiounTransparent Display
Opléisung1920×1080
Zesummesetzunga-Si TFT-LCD , CELL
Hellegkeet
CR5000:1
Faarwen16.7M
GéigeliichtNo
InterfaceLVDS
Panel MarkChimei Innolux
Panel Gréisst50"
Resolutioun1920(RGB)×1080, FHD, 44PPI
Affichage Beräich1095.84(W)×616.41(H) mm
Kontur Gréisst1112.32(W)×631.61(H) ×1.31(D) mm
Hellegkeet0 cd/m²
Vue Wénkel88/88/88/88 (Typ.)(CR≥20)
beschte Vue opSymmetry
Glas Déift0.50+0.50 mm
weisen Faarwen16.7M   70% NTSC
Frequenz60Hz
Chauffeur icCOF Built-in 6 source + 4 gate chips
Panel Gewiicht1.99±0.19Kgs
Signal InterfaceLVDS (2 ch, 8-bit) , 51 pins Connector
Input Volt12.0V (Typ.)
ËmweltOperating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
Panel ModellV500HJ1-PE8 Rev.C3
Panel Typa-Si TFT-LCD , CELL
Pixel FormatRGB Vertical Stripe
bezel Ouverture-
UewerflächAntiglare (Haze 1%), Hard coating (3H)
Kontrast Verhältnis5000:1 (Typ.) (TM)
Display ModusSuper MVA, Normally Black, Transmissive
Äntwert Zäit8.5 (Typ.)(G to G)
transmissivitéit5.6% (Typ.)(with Polarizer)
Lampe TypNo B/L
TouchscreensWithout
ApplikatiounTransparent Display
Famill Modell
LC500DUE-SFR1 LG Display 50 1920×1080
LC500EUD-FFF3 LG Display 50 1920×1080
T500HVN04.1 CELL AUO 50 1920×1080
T500HVN04.5 CELL AUO 50 1920×1080
T500QVN01.1 CELL AUO 50 3840×2160
V500HJ1-L01 Innolux 50 1920×1080
V500HJ1-LE6 Innolux 50 1920×1080
V500HJ1-PE6 Innolux 50 1920×1080
V500HJ1-PE8 Innolux 50 1920×1080
V500HK1-LS6 Rev.C7 Innolux 50 1920×1080
