| Part Number | V400HJ6-PE1 Rev.CA |
| Mark | Innolux |
| Gréisst | 40 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | CELL, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 16.7M |
| Géigeliicht | No B/L |
| Interface | LVDS |
| Fabrikant beschwéiert | Innolux |
| Modell Numm | V400HJ6-PE1 Rev.CA |
| Écran Gréisst | 40 inch |
| Écran Typ | CELL, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 55PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 878.112 × 485.352 (H×V) |
| Kontur (mm) | 888.392 × 494.152 × 1.29 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare (Haze 1%), Hard coating (3H) |
| luminance | 0 cd/m² |
| Kontrast Verhältnis | 5000 : 1 (Typ.) (TM) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Äntwert | 8.5 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | MVA, Normally Black, Transmissive |
| Glas deck | 0.50+0.50 mm |
| transmissivitéit | 5.5% (Typ.)(with Polarizer) |
| Faarfdéift | 16.7M 72% NTSC |
| mass | 1.40±0.07Kgs |
| benotzt fir | TV Sets |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Chauffer ic Lëscht | Built-in COF 8 source + 4 gate chips |
| Signal Typ | LVDS (2 ch, 8-bit) , Connector 51 pins |
| Spannungsversuergung | 12.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LTA400HL15 | Samsung | 40 | 1920×1080 |
| LTA400HM01 | Samsung | 40 | 1920×1080 |
| LTA400HM13 | Samsung | 40 | 1920×1080 |
| LTI400HA02 | Samsung | 40 | 1920×1080 |
| T400HW03 V0 | AUO | 40 | 1920×1080 |
| T400HW04 V2 | AUO | 40 | 1920×1080 |
| T400XW01 V6 | AUO | 40 | 1366×768 |
| V400DK1-KE1 | Innolux | 40 | 3840×2160 |
| V400DK2-KS5 | Innolux | 40 | 3840×2160 |
| V400HJ6-PE1 | Innolux | 40 | 1920×1080 |
