| Part Number | V400HJ6-LE8 Rev.F9 |
| Mark | Innolux |
| Gréisst | 40 |
| Applikatioun | TV Sets |
| Opléisung | 1920×1080 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 5000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , 30K hours |
| Interface | LVDS |
| Fabrikant beschwéiert | Innolux |
| Modell Numm | V400HJ6-LE8 Rev.F9 |
| Écran Gréisst | 40 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×1080 (FHD) 55PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 878.112 × 485.352 (H×V) |
| Kontur (mm) | - |
| luminance | - |
| Kontrast Verhältnis | 5000 : 1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Äntwert | 9.5 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | Super MVA, Normally Black, Transmissive |
| Faarfdéift | 16.7M 72% NTSC |
| mass | - |
| benotzt fir | TV Sets |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 8-bit) , Connector 51 pins |
| Spannungsversuergung | 12.0V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
