| Part Number | V290BJ1-L01 |
| Mark | Innolux |
| Gréisst | 29.0 |
| Applikatioun | LCTV |
| Opléisung | 1366×768 |
| Zesummesetzung | LCM |
| Hellegkeet | 300 |
| CR | 2500:1 |
| Faarwen | 16.7M |
| Géigeliicht | CCFL |
| Interface | LVDS |
| Panel Mark | CMO |
| Panel Modell | V290BJ1-L01 |
| Panel Typ | a-Si TFT-LCD , LCM |
| Panel Gréisst | 29.0 inch |
| Resolutioun | 1366(RGB)×768 , WXGA |
| Display Modus | Super MVA, Normally Black, Transmissive |
| aktiv Beräich | 631.092×354.816 mm |
| skizzéieren | 654.8×380.7 mm |
| Uewerfläch | Antiglare (Haze 3.5%) |
| Hellegkeet | 300 cd/m² (Typ.) |
| Kontrast Verhältnis | 2500:1 (Typ.) |
| weisen Faarwen | 16.7M (8-bit), CIE193172% |
| Äntwert Zäit | 8.5 (Typ.)(G to G) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| Frequenz | 60Hz |
| Lampe Typ | 3 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 30 pins |
| Input Volt | 12.0V (Typ.) |
| Applikatioun | LCTV |
