| Part Number | V236BJ1-LE2 Rev.CA |
| Mark | Innolux |
| Gréisst | 23.6 |
| Applikatioun | TV Sets |
| Opléisung | 1366×768 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | LVDS |
| Mark | Innolux |
| Modell | V236BJ1-LE2 Rev.CA |
| diagonal Gréisst | 23.6 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1366(RGB)×768 [WXGA] 66PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 521.471(H)×293.184(V) mm |
| kontur dim. | - |
| luminance | - |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 8.5 (Typ.)(G to G) |
| Vue Wénkel | 89/89/89/89 (Typ.)(CR≥10) |
| Betribssystemer Modus | AAS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 72% NTSC |
| Liichtquell | WLED |
| Gewiicht | - |
| entworf fir | TV Sets |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Stroumversuergung | 12.0V (Typ.) |
| Ëmwelt | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
