| Part Number | TX54D31VC0CAB |
| Mark | KOE |
| Gréisst | 21.3 |
| Applikatioun | Industrial |
| Opléisung | 1600×1200 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 500:1 |
| Faarwen | 16.7M |
| Géigeliicht | 6 pcs CCFL |
| Interface | LVDS |
| Fabrikant beschwéiert | KOE |
| Modell Numm | TX54D31VC0CAB |
| Écran Gréisst | 21.3 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1600(RGB)×1200 (UXGA) 94PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 432 × 324 (H×V) |
| Kontur (mm) | 460.6 × 362 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Antiglare |
| luminance | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 500 : 1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Äntwert | 15/10 (Typ.)(Tr/Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | IPS, Normally Black, Transmissive |
| Faarfdéift | 16.7M |
| mass | 2.700/3.00Kgs (Typ./Max.) |
| benotzt fir | Industrial |
| Erfrëschungsrate | - |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 8-bit) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
