| Part Number | TX18D211VM0BAA |
| Mark | KOE |
| Gréisst | 7.0 |
| Applikatioun | Industrial Outdoor H |
| Opléisung | 800×480 |
| Zesummesetzung | LTPS TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | WLED |
| Interface | LVDS |
| Panel Mark | KOE |
| Panel Modell | TX18D211VM0BAA |
| Panel Gréisst | 7.0" |
| Panel Typ | LTPS TFT-LCD, LCM |
| Resolutioun | 800(RGB)×480, WVGA, 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Affichage Beräich | 152.4(W)×91.44(H) mm |
| bezel Ouverture | 156.2(W)×94.5(H) mm |
| Kontur Gréisst | 167.7(W)×109.5(H) ×20.3(D) mm |
| Uewerfläch | - |
| Hellegkeet | 1200 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Display Modus | IPS, Normally Black, Transmissive |
| beschte Vue op | Symmetry |
| Äntwert Zäit | 30 (Typ.)(Tr+Td) |
| weisen Faarwen | 262K 73% NTSC |
| Lampe Typ | WLED , 50K hours , With LED Driver |
| Frequenz | 60Hz |
| Touchscreens | Without |
| Panel Gewiicht | 219g (Typ.) |
| Applikatioun | Industrial Outdoor High Brightness Automotive Display |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LMS700KF01-001 | Samsung | 7.0 | 800×480 |
| LQ070T5BG01 | SHARP | 7.0 | 480×234 |
| LQ070Y3LW01 | SHARP | 7.0 | 800×480 |
| LR700BA9005 | Innolux | 7.0 | 480×234 |
| LW700AT9008 | Innolux | 7.0 | 800×480 |
| TX18D37VM0ARA | KOE | 7.0 | 800×480 |
