| Part Number | TX16D204VM0BAA |
| Mark | KOE |
| Gréisst | 6.3 |
| Applikatioun | Industrial |
| Opléisung | 800×280 |
| Zesummesetzung | a-Si TFT-LCD , LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 262K |
| Géigeliicht | 3S3P |
| Interface | CMOS |
| Panel Mark | KOE |
| Panel Gréisst | 6.3" |
| Resolutioun | 800(RGB)×280, 135PPI |
| Affichage Beräich | 150(W)×52.5(H) mm |
| Kontur Gréisst | 167(W)×69(H) ×9.5(D) mm |
| Hellegkeet | 500 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| beschte Vue op | Symmetry |
| weisen Faarwen | 262K 52% NTSC |
| Frequenz | 60Hz |
| Panel Gewiicht | 107g (Typ.) |
| Signal Interface | CMOS (1 ch, 6-bit) , 50 pins FPC |
| Input Volt | 3.3V (Typ.) |
| Ëmwelt | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| Panel Modell | TX16D204VM0BAA |
| Panel Typ | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| bezel Ouverture | 153(W)×55.5(H) mm |
| Uewerfläch | - |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Display Modus | IPS, Normally Black, Transmissive |
| Äntwert Zäit | 40 (Typ.)(Tr+Td) |
| Lampe Typ | 3S3P WLED , 50K hours , Without Driver |
| Touchscreens | Without |
| Applikatioun | Industrial |
| ES063TC1 | E Ink | 6.3 | 200×1040 |
| G321DX5R1AC | SII | 6.3 | 320×200 |
| LS063K3SX01 | SHARP | 6.3 | 720×1280 |
| LS063K3SX54 | SHARP | 6.3 | 720×1280 |
| LS063R1SX01 | SHARP | 6.3 | 1440×2560 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
