| Part Number | TX11D201VM0BAA |
| Mark | KOE |
| Gréisst | 4.2 |
| Applikatioun | Automotive Display |
| Opléisung | 480×272 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1500:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | Parallel |
| Mark | KOE |
| Modell | TX11D201VM0BAA |
| diagonal Gréisst | 4.2 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 131PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 92.88(H)×52.632(V) mm |
| kontur dim. | 102.5(H)×69(V) ×15.5(D) mm |
| bezel Beräich | 95.28(H)×55.07(V) mm |
| Behandlung | Antiglare, Hard coating (2H) |
| luminance | 750 cd/m² (Typ.) |
| Kontrast Verhältnis | 1500:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 65% NTSC |
| Liichtquell | WLED [6S1P] , 50K hours , With LED Driver |
| Gewiicht | 97.0g (Typ.) |
| entworf fir | Automotive Display |
| Frame Taux | 60Hz |
| Touch Panel | Without |
| Interface Typ | Parallel RGB (1 ch, 8-bit) , 68 pins Connector |
| Stroumversuergung | 3.3V (Typ.) |
| Ëmwelt | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
