| Part Number | TV122WXM-AL0 |
| Mark | BOE |
| Gréisst | 12.2 |
| Applikatioun | Laptop |
| Opléisung | 1280×800 |
| Zesummesetzung | LCM , a-Si TFT-LCD |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED , No Driver |
| Interface | eDP |
| Fabrikant beschwéiert | BOE |
| Modell Numm | TV122WXM-AL0 |
| Écran Gréisst | 12.2 inch |
| Écran Typ | LCM , a-Si TFT-LCD |
| Pixel Zuel | 1280(RGB)×800 (WXGA) 123PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 262.565 × 164.16 (H×V) |
| Kontur (mm) | 278.46 × 193.26 × 3.4 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Hard coating |
| luminance | 350 cd/m² (Typ.) |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Äntwert | 30 (Typ.)(Tr+Td); 45 (Typ.)(G to G) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | ADS, Normally Black, Transmissive |
| Faarfdéift | 16.7M 50% NTSC |
| kontur Form | - |
| benotzt fir | Laptop |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | eDP (1 Lane) , eDP1.2 , HBR1 (2.7G/lane) , 30 pins Connector |
| Spannungsversuergung | 3.3V (Typ.) |
| max. Bewäertungen | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
