| Part Number | TV105WUM-AS0 |
| Mark | BOE |
| Gréisst | 10.5 |
| Applikatioun | Pad & Tablet |
| Opléisung | 1200×1920 |
| Zesummesetzung | Assembly , a-Si TF |
| Hellegkeet | |
| CR | 900:1 |
| Faarwen | 16.7M |
| Géigeliicht | 4 strings WLED , No Driver |
| Interface | MIPI |
| Fabrikant beschwéiert | BOE |
| Écran Gréisst | 10.5 inch |
| Pixel Zuel | 1200(RGB)×1920 (WUXGA) 215PPI |
| aktiv Beräich (mm) | 141.3 × 226.08 (H×V) |
| Bezel Beräich (mm) | - |
| luminance | 480 cd/m² (Typ.) |
| Vue Wénkel | 85/85/85/85 (Typ.)(CR≥10) |
| gutt Vue op | Symmetry |
| Faarfdéift | 16.7M 92% DCI-P3 |
| mass | 216g (Typ.) |
| Erfrëschungsrate | 60Hz |
| Signal Typ | MIPI (4 data lanes) , 34 pins Connector |
| Spannungsversuergung | 1.8/5.8/-5.8V (Typ.)(VDD/VSP/VSN) |
| max. Bewäertungen | Storage Temp.: -55 ~ 125 °C Operating Temp.: -20 ~ 85 °C |
| Modell Numm | TV105WUM-AS0 |
| Écran Typ | Assembly , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Kontur (mm) | 156.18 × 255.06 × 4.44 (H×V×D) |
| Behandlung | Hard coating |
| Kontrast Verhältnis | 900 : 1 (Typ.) (TM) |
| Äntwert | 25 (Typ.)(Tr+Td) ms |
| Aarbecht Modus | - |
| benotzt fir | Pad & Tablet |
| touchscreen | PCAP |
