| Part Number | TPM0501010P |
| Mark | JDI |
| Gréisst | 5.0 |
| Applikatioun | Mobile Phone |
| Opléisung | 1080×1920 |
| Zesummesetzung | a-Si TFT-LCD, LCM |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | WLED |
| Interface | MIPI |
| Mark | JDI |
| Modell | TPM0501010P |
| diagonal Gréisst | 5.0 inch |
| Typ | a-Si TFT-LCD, LCM |
| Pixel Format | 1080(RGB)×1920 [FHD] 445PPI |
| Configuratioun | RGB Vertical Stripe |
| aktiv Beräich | 61.641(H)×109.584(V) mm |
| kontur dim. | 64.04(H)×116.52(V) ×1.48(D) mm |
| luminance | 450 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000:1 (Typ.) (TM) |
| Vue Richtung | Symmetry |
| Äntwert Zäit | 25 (Typ.)(Tr+Td) |
| Vue Wénkel | 80/80/80/80 (Typ.)(CR≥10) |
| Betribssystemer Modus | IPS, Normally Black, Transmissive |
| Ënnerstëtzung Faarf | 16.7M 85% NTSC |
| Liichtquell | WLED [7S2P] , W/O Driver |
| Gewiicht | TBD |
| entworf fir | Mobile Phone |
| Frame Taux | 60Hz |
| Touch Panel | In-Cell Touch |
| Interface Typ | MIPI (4 data lanes) , 40 pins Connector |
| Stroumversuergung | 1.8/5.5/-5.5V (Typ.)(IOVCC/AVDD/AVEE) |
| Ëmwelt | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
