| Part Number | TM103XDKP38-00 |
| Mark | TIANMA |
| Gréisst | 10.3 |
| Applikatioun | Outdoor High Brightn |
| Opléisung | 1920×720 |
| Zesummesetzung | LCM, a-Si TFT-LCD |
| Hellegkeet | |
| CR | 1000:1 |
| Faarwen | 16.7M |
| Géigeliicht | 8S3P WLED , 10K hours , No Driver |
| Interface | LVDS |
| Fabrikant beschwéiert | TIANMA |
| Modell Numm | TM103XDKP38-00 |
| Écran Gréisst | 10.3 inch |
| Écran Typ | LCM, a-Si TFT-LCD |
| Pixel Zuel | 1920(RGB)×720 200PPI |
| Arrangement | RGB Vertical Stripe |
| aktiv Beräich (mm) | 243.648 × 91.368 (H×V) |
| Kontur (mm) | 261.04 × 109.3 (H×V×D) |
| Bezel Beräich (mm) | - |
| Behandlung | Hard coating, Reflection 5.5% (Typ.) |
| luminance | 800 cd/m² (Typ.) |
| Kontrast Verhältnis | 1000 : 1 (Typ.) (TM) |
| Vue Wénkel | 88/88/88/88 (Typ.)(CR≥10) |
| Äntwert | 20 (Typ.)(Tr+Td) ms |
| gutt Vue op | Symmetry |
| Aarbecht Modus | SFT, Normally Black, Transmissive |
| Faarfdéift | 16.7M 74% NTSC |
| mass | TBD |
| benotzt fir | Outdoor High Brightness Automotive Display |
| Erfrëschungsrate | 60Hz |
| touchscreen | Without |
| Signal Typ | LVDS (2 ch, 8-bit) , Connector 50 pins |
| Spannungsversuergung | 3.3/3.3V (Typ.)(VDD/AVDD) |
| max. Bewäertungen | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
